Compact, ceiling-mounted WiFi 5 AP with 6 spatial streams ideal for smaller offices.

WiFi 5

6 spatial streams

140 m² (1,500 ft²) coverage

200+ connected devices

Powered using PoE*

GbE uplink

Wall-mounted WiFi 6 AP with 6 spatial streams and a built-in 4-port switch ideal for single-room coverage in hospitality environments.

WiFi 6

6 spatial streams

115 m² (1,250 ft²) coverage

300+ connected devices

Powered using PoE/PoE+*

(4) GbE ports with (1) PoE output

GbE uplink

Entry-level, ceiling-mounted WiFi 5 AP with 4 spatial streams designed for small offices.

WiFi 5

4 spatial streams

115 m² (1,250 ft²) coverage

250+ connected devices

Powered using PoE*

GbE uplink

– Ports:

   + (1) uplink Gigabit Ethernet port (E0), with POE-in support (802.3at/802.3af);

   + (3) downlink Gigabit Ethernet ports (E1-E3), with POE-out on E3 (802.3af);

– Certifications:

   + UL 2043 plenum rating;

+ EN 60601-1-1 and EN 60601-1-2 (for deployment in medical environments);

   + Wi-Fi Alliance certified (WFA) 802.11ac with Wave 2 (Wi-Fi 5), WPA2, WPA3, Enhanced Open (OWE).

– Input voltage:

   + Power over Ethernet (POE) on E0: 802.3af (class 3) or 802.3at (class 4). When using 802.3af, POE-out on E3 is disabled

   + DC power (48V): No restrictions.

   + Power sources are sold separately.

– Wi-Fi antenna: Integrated directional antennas with maximum individual antenna gain of 4.3dBi in 2.4GHz and 6.2dBi in 5GHz.

– Connectivity, standard: IEEE 802.11ac, 802.11n.

– Radio coverage:

   + Dual Radio for simultaneous dual-band operation;

   + 5GHz 802.11ac 2×2 MIMO for up to 867Mbps wireless data rate, with Multi User MIMO support (Wi-Fi 5);

   + 2.4GHz 802.11n 2×2 MIMO for up to 300 Mbps wireless data rate (Wi-Fi 4);

– Differentiator: Aruba Instant On AP11D Desk/Wall Access Points offer a reliable, affordable, and business-grade Wave 2 802.11ac Wi-Fi experience for low- to medium-density small business environments requiring enhanced security and high performance like medical clinics, SOHO, or Airbnb. These cost-effective access points are ideal for small businesses scaling up to 25 access points without additional cost and complexity. Regulatory domain of Rest of World. Bundle includes AP and power supply unit.

– Weight: 313g.

– Dimensions: 150 x 86 x 40 mm.

– Aruba Instant On AP12 (RW) Indoor AP with DC Power Adapter and Cord (EU) Bundle.

– Ports: (1) uplink Gigabit Ethernet port, with POE-in support (802.3af).

– Wi-Fi antenna: Integrated downtilt omni-directional antennas with maximum individual antenna gain of 3.9dBi in 2.4GHz and 5.4dBi in 5GHz.

– Connectivity, standard: IEEE 802.11ac, 802.11n.

– Certifications:

   + UL 2043 plenum rating;

+ EN 60601-1-1 and EN 60601-1-2 (for deployment in medical environments);

   + Wi-Fi Alliance certified (WFA) 802.11ac with Wave 2 (Wi-Fi 5), WPA2, WPA3, Enhanced Open (OWE).

– Input voltage:

   + Power over Ethernet (PoE): 802.3af (class 3);

   + DC power (12V).

   + Note: Power sources are sold separately.

– Radio coverage: Dual Radio for simultaneous dual-band operation. 5GHz 802.11ac 3×3 MIMO for up to 1300Mbps wireless data rate, with Multi User MIMO support (Wi-Fi 5). 2.4GHz 802.11n 2×2 MIMO for up to 300Mbps wireless data rate (Wi-Fi 4).

– Dimensions: 34 x 157 x 157 mm.

– Weight: 483g.

– The HPE Networking Instant On Access Point AP32 is a Wi-Fi CERTIFIED 6E™ wireless access point built to bring future-ready connectivity to small and medium businesses. The HPE Networking Instant On AP32 supports the new 6E wireless protocol that broadcasts on the 6GHz band, which is reserved for Wi-Fi 6E-enabled devices, and offers higher capacity and capability for the devices. This higher capacity needs a strong backhaul, so the HPE Networking Instant On AP32 comes with a 2.5GbE uplink port and PoE to make connectivity and power easy. With a 2×2 antenna array supporting 2 spatial streams, the HPE Networking Instant On AP32 provides robust connectivity for up to 75 devices and 2.8Gbps of wireless throughput.

Technical specifications

– Differentiator: HPE Networking Instant On Access Point AP32 is for businesses that have invested in PoE infrastructure throughout their facility, as these SKUs will ship without a PSU.

– Certifications: Wi-Fi Certified 6.

– Input voltage: PoE 802.3bt (class 6) or 802.3at (class 4) DC power (12V).

– Wi-Fi antenna: Dual Omnidirectional 2×2 MIMO.

– Connectivity, standard: Wi-Fi 11ax.

– Ports: 1x 2.5GbE BaseT Uplink DC Power Connector LED status Indicators Reset/LED control button Kensington security slot.

– Mounting: Ceiling/Wall mount clip.

– Power consumption: 12.9W (PoE) 11.0W (DC).

– Radio coverage: Tri-band 802.11ax 2×2 6Ghz/5Ghz/2.4Ghz MU-MIMO.
