Description
Features
- Six labeled call buttons (blank template included)
- SIP Compliant
- ONVIF® Profile S Compliant
- PoE with PoE pass-through
- Camera vertical adjustment +15º, 0º, or -8º (manual)
- White LED for low-light illumination
- Capture and store the audio and video of active conversations on a microSD™ card (not provided by Aiphone)
- Weather and vandal-resistant
- Stainless steel faceplate
- 2 contact outputs
Specs
Power Source:
PoE (IEEE 802.3af class 0) or 24V DC (PS-2420UL)
Power Draw:
5.28W
Camera:
1/3″ CMOS 1.23 megapixel
Min. illumination:
5 lux
Audio Codec:
G.711 (µ-law, A law), G.722
Video Codec:
H.264/AVC, motion JPEG
Volume
73dB-96dB
Port Security:
IEEE 802.1X
UL Listed:
UL 62368-1 cUL 62368-1
Operating Temp:
-40° ~ 140°F (-40° ~ 60°C)
Protection:
IP65, IK08
Dimensions:
13-11/16″ H x 7-3/16″ W
